UHF Lightning Arrestor PL-259 Lightning Surge Protector PL259 Plug (UHF Male) to SO239 Socket (UHF Female) Bulkhead

It is a great UHF lightning protection solution for Ham radio . This model features PL259(UHF male) Plug TO SO239 Socket(UHF Female) for mounting through an enclosure wall or the arrestor can be used inline. SO239 259 arrester will pass DC,so SO-239 surge protector is suitable for applications where DC is carried through the coax cable. Both UHF connector ports of this unit are equally protected -- it can be installed in either orientation. A ground lug and terminal on the housing provide superior grounding. Specification: Frequency Range: DC-1GHz Discharge Voltage: DC90V Impedance: 50 ohms Insertion Loss: <0.1 dB VSWR:1.2 Max Power: 50W Max surge voltage let through:200 mV Throughput Energy: 5 nJ Max Current Load: 10A RoHS: Yes Packing : 1 piece UHF male to female Bulkhead lightning arrestor

• 1.UHF Lightning Arrester,PL259(UHF male) Plug TO SO239 Socket( UHF Female) ,PL-259 Lightning surge protector for cable. With ground screw connection for easy install
• 2.Run a piece of heavy gauge copper wire (8 or 10 gauge) from the grounding screw on the side of the arrestor to a 3 foot minimum length grounding rod driven into the ground
• 3.High quality construction,DC-1GHz, insertion loss 0.1dB and VSWR 1.2 ,Replaceable 90V Gas Tube Element with High Surge Power CapabilityHigh Surge Power Capability
• 4.A great UHF PL259 arrestor to protect your life, protectors offer HF/VHF/UHF other frequency equipment with extremely low loss. They boast an insertion loss of less than 0.1 dB.
• 5.SO239 arresters should be installed as close as possible to the equipment to be protected, often at the point where the cable enters the building.
