EPS-120-15 120W 15V Industrial Open Frame Switching Power Supply 110V/220VAC to 15V 8A Green PCB Power Unit PSU

Power ConvertersEPS-120-15 120W 15V Industrial Open Frame Switching Power Supply 110V/220VAC to 15V 8A green PCB power unit PSUFeatures4"x 2"compact sizeFull range 80~264VAC input EMI Class B for Class I (with FG) and Class II(without FG) configuration<; 0.3WHigh efficiency up to 91%Protections: short circuit/overload/over voltage/over temperatureCooling by free air convection for 84W and 120W with 10CFM forced airBuilt-in 12V/0.5A FAN supplyLED indicator for power onOperating altitude up to 5000 metersDescriptionEPS-120 is a 120W highly reliable green PCB type power supply with a high power density on the 4 by 2 footprint. It accepts 80~264VAC input and offers various output voltages between 12V and 48V. The working efficiency is up to 92% and the extremely low no load power consumption is down below 0.3W. EPS-120 is able to be used for both Class I (with FG) and Class II(no FG) system design.EPS-120 is equipped with complete protection functions; it is complied with the international safety regulations such as TUV EN62368-1, UL62368-1 and IEC62368-1. EPS-120 series serves as a high price-to-performance power supply solution for various industrial applications.
